Air hydraulic pump JPL 15
Oil volume complete: 1,5 L
Product information "Air hydraulic pump JPL 15"
- Sturdy construction, yet lightweight and easy to handle.
- Pressure limiting valve provides safety against overloading.
- Optimally compatible with our hydraulic jacks.
- Pumps are equipped with integrated quick-lift for faster working.
- JPL 15 with adjustable working pressure.
| Air connection (bar): | 7-14 |
|---|---|
| Connections (pcs.): | 2 |
| Dimensions L x W x H (mm): | 380 x 136 x 185 |
| Flow rate with load (L/min): | 0,18 |
| Flow rate without load (L/min): | 1,07 |
| Oil volume complete/usable (L): | 1,5/1,5 |
| Weight (kg): | 9 |
| Working pressure (bar): | 0-700 (verstellbar) |
