JUNG Hebe- und Transporttechnik GmbH
Transport trolley JLA-e 5/12 G facelift
The electric-powered transport trolley JLA-e 5/12 G is easy to operate and does not require an additional towing vehicle. Suitable for loads up to 12 tons.
Load capacity: 5 t
Height: 180 mm
Electric powered transport trolley
Height: 180 mm
Electric powered transport trolley
Product number:
22 005 200-G
Weight:
186 kg
Product information "Transport trolley JLA-e 5/12 G facelift"
Advantages of Electric Powered Transport Trolleys
-
No separate towing vehicle required.
- Convenient, with battery and handy remote control! Based on 2.4 GHz, with a cable connection port, single or dual-hand operation, vibration feedback, etc.
- High runtime (under full load in ideal conditions) thanks to a directly driven motor. Transport trolley JLA-e 5/12 G: approx. 4-5 hours.
- The new generation of drives prevents rolling away, even when switched off.
- The new battery indicator displays various parameters in real-time, such as voltage, current, or state of charge.
- Short charging time due to an optimized charger. Charging time for the JLA-e 5/12 G transport trolley: approx. 3-4 hours.
- 360° rotatable.
- Infinitely variable speed control.
- The advanced LiFePo4 cell technology with higher energy density allows for a more compact design.
- Compatible with the G series castors. The trolleys are not included in the delivery.
- Also available with lift. See here.
- Side cover plates with JUNG lettering provide dirt protection and an attractive design.
- Tested according to DGUV V68 (D).
| Battery and charger: | 1 x |
|---|---|
| Castor dimensions (Ø x l mm): | 140 x 59 |
| Dimensions (mm): | 750 x 900 |
| Height (mm): | 180 |
| Load capacity (t): | 5 |
| Number of castors (Pieces): | 4 |
| Operating mode in acc. with VDE 0530: | S1 |
| Operational time (h): | 4 - 5 |
| Pulling capacity (t): | 12 |
| Remote control, charger and belt with holder: | 1 x |
| Speed (m/min): | 10 |
| Supporting surface of turnable Ø (mm): | 150 |
| Weight battery + box (kg): | 45 |
| Weight charger (kg): | 2 |
| Weight without battery + controller (kg): | 146 |
