JUNG Hebe- und Transporttechnik GmbH
Container trolley JTLB 30 G Twistlock
For transporting containers - the tandem trolleys JTLB 30 G TL with twistlock for loads up to 30 t.
Load capacity: 30 t (in a set 60 t*)
Height: 215 mm
ISO-length: 2260 mm
*) Set consisting of JTL 30 G TL + JFB 30 G TL
Height: 215 mm
ISO-length: 2260 mm
*) Set consisting of JTL 30 G TL + JFB 30 G TL
Product number:
12 303 140-TL
Weight:
283 kg
Product information "Container trolley JTLB 30 G Twistlock"
Advantages of the tandem trolleys JTLB 30 G TL with Twistlock
- Safe transport of containers.
- Low height for moving containers low to the ground.
- Lock-to-hold mechanism between the trolley and the containers (Twistlock).
- Compatible with all ISO-containers.
- “Twistlock” version for outdoor transport for use on pavement includes turntables fitted with “Twistlock” to secure containers to transport trolleys. Including 2-parts connecting bars fixed length 2.26 m / 89 inch and pulling handle with towing eye.
| Castor dimensions (Ø x l mm): | 140 x 59 |
|---|---|
| Dimensions steerable (mm): | 1 620 x 2 870 |
| Handlebar with pulling eye (mm): | 1 230 |
| Height (mm): | 215 |
| ISO-length (mm): | 2 260 |
| Load capacity (t): | 30 |
| Number of castors (Pieces): | 24 |
| Supporting surface of turnable Ø (mm): | 215 |
| Total height (mm): | 300 |
| Weight JUWAthan®plus (kg): | 283 |
