JUNG Hebe- und Transporttechnik GmbH
Steerable trolley JLB 40 H Professional - NEW
Strength and reliability combined: The JLB 40 H transport trolley from JUNG handles loads up to 40 t with a compact installation height of just 230 mm.
Load capacity: 40 t (in a set 80 t*)
Height: 230 mm
Transport trolleys series H professional
*) Set consisting of JLB 40 H + JFB 40 H
Height: 230 mm
Transport trolleys series H professional
*) Set consisting of JLB 40 H + JFB 40 H
Product number:
09 401 206-H
Weight:
274 kg
Product information "Steerable trolley JLB 40 H Professional - NEW"
Features of the JUNG Transport trolleys JLB 40 H Professional
- Despite their very high load capacity, these transport trolleys remain compact and lightweight.
- The redesigned steering unit features fewer rollers, allowing for a more compact design without compromising load capacity – made possible by advanced roller technology.
- The new, more compact construction and reduced number of rollers result in a noticeable weight reduction.
- By halving the roller width and doubling the number of rollers, steering movements are significantly improved and friction during cornering is greatly reduced.
- The mechanical pendulum mounting of the cassettes and axles ensures even load distribution across the rollers and the floor surface – eliminating the need for complex and failure-prone hydraulic compensation systems.
- All transport trolleys are delivered fully assembled and ready for immediate use. The steering unit is supplied with a ball-bearing turntable and drawbar; the drawbar is equipped with a towing eye.
JUNG transport trolleys are fitted with ball-bearing rollers for smooth and effortless movement. The rollers come standard with a low-wear tread.
| Castor dimensions (Ø x l mm): | 200 x 85 |
|---|---|
| Dimensions steerable (mm): | 650 x 1 060 |
| Handlebar with pulling eye (mm): | 1 600 |
| Height (mm): | 230 |
| Load capacity (t): | 40 |
| Number of castors (Pieces): | 12 |
| Supporting surface of turnable Ø (mm): | 250 |
| Weight JUWAthan® (kg): | 274 |
